Product Description
Item |
Details |
Product Name |
Customized Portal Frame Steel Structure Warehouse/Workshop/Hangar |
Main Steel Frame |
Welded steel beams and columns |
Secondary Frame |
Hot-dip galvanized purlin, steel bracing, tie bar, knee brace, edge cover, etc. |
Roof Panel |
Glass wool sandwich panel (optional: Rock wool sandwich panel, PU sandwich panel, Corrugated steel sheet) |
Wall Panel |
Glass wool sandwich panel / Corrugated steel sheet |
Connection Mode |
High-strength bolt connection + Partial welding |
Tie Rod |
Circular steel tube (Hot-dip galvanized surface treatment) |
Knee Brace |
Q235B Angle Steel (Galvanized/painted surface) |
Brace |
Q235B Round Bar / Angle Steel (Hot-dip galvanized treatment) |
Door Configuration |
Roller shutter door (Large cargo access) / Access door (Personnel access) |
Window Configuration |
Fixed window / Sliding window |
Ventilation System |
Roof ventilator (Natural ventilation) / Side wall ventilation window |
Design Parameters |
Customized based on project site size , load capacity, local building codes and customer functional requirements |
Product Features
-
Quick Erection & Cost EfficiencyAll components are prefabricated in the factory and assembled by bolts or welded on site, greatly shortening the construction period and reducing labor and foundation costs. The steel structure is durable with low maintenance, helping you put the building into use quickly and achieve earlier returns. -
Flexible Design & ExpandabilityLarge-span structure creates open space. Customizable height, layout and functions make it suitable for various industrial scenes and easy for future expansion. -
Strong Durability & Green PropertyExcellent structural safety and weather resistance. Professional anti-rust and fire protection ensure long service life. Recyclable material supports sustainable development.
Application
